8. MPI Implementation

This chapter describes how PICLas subroutines and functions are parallelized. Please also read the general rules for using MPI.

8.1. General Remarks: Things to consider

Debug MPI

mpirun --mca mpi_abort_print_stack 1 -np 3 ~/piclas/build/bin/piclas parameter.ini DSMC.ini

8.2. Construction of Halo Region (MPI 3.0 Shared Memory)

The general idea is to have the geometry information in a shared memory array on each node. This reduces the memory overhead and removes the need for halo regions between processors on the same node. An exemplary unstructured mesh is given in Fig. 8.1. The workflow is as follows:

1. Load the complete mesh into a shared memory window that is solely allocated by the compute-node root processor of size 1:nTotalElems (only node coords, not derived properties, such as metric terms).

2. Load the elements that are assigned to processors on a single compute-node into an array of size 1:nSharedElems (red elements in Fig. 8.1).

3. Find the compute-node halo elements and store in an array of size 1:nSharedHaloElems (blue elements in Fig. 8.1).

   1. Background mesh (BGM) reduction

   2. Shared sides reduction

   3. Halo communicator

Fig. 8.1 Node local (red), halo (blue) and complete mesh (white). The red and blue geometry information is allocated once on each node and available to all processors on that node

8.2.1. Mesh Geometry

The complete mesh geometry is read-in by each compute-node and available through the ElemInfo_Shared, SideInfo_Shared, NodeInfo_Shared, NodeCoords_Shared arrays. Other derived variables and mappings (e.g. in MOD_Particle_Mesh_Vars) are usually only available on the compute-node.

8.2.1.1. ElemInfo

Element information is read-in and built in ReadMeshElems

ElemInfo_Shared(1:ELEMINFOSIZE,1:nGlobalElems)
! Possible preprocessor variables for first entry
! ElemInfo from mesh file
ELEM_TYPE         1    ! PyHOPE classification of element (currently not used)
ELEM_ZONE         2    ! Zone as defined in PyHOPE (currently not used)
ELEM_FIRSTSIDEIND 3    ! Index of the first side belonging to the element
ELEM_LASTSIDEIND  4    ! Index of the last side belonging to the element
ELEM_FIRSTNODEIND 5    ! Index of the first node belonging to the element
ELEM_LASTNODEIND  6    ! Index of the last node belonging to the element
! ElemInfo for shared array (only with MPI)
ELEM_RANK         7    ! Processor rank to which the element is assigned
ELEM_HALOFLAG     8    ! Element type:  1 = Regular element on compute node
                       !                2 = Halo element (non-periodic)
                       !                3 = Halo element (periodic)

8.2.1.2. SideInfo

Side information is read-in and built in ReadMeshSides

SideInfo_Shared(1:SIDEINFOSIZE+1,1:nNonUniqueGlobalSides)
! Possible preprocessor variables for first entry
SIDE_TYPE         1    ! PyHOPE classification of side
SIDE_ID           2    ! tbd
SIDE_NBELEMID     3    ! Neighbouring element ID
SIDE_FLIP         4    ! tbd
SIDE_BCID         5    ! Index of the boundary as given parameter.ini
SIDE_ELEMID       6    ! Element ID
SIDE_LOCALID      7    ! Local side ID
SIDE_NBSIDEID     8    ! Neighbouring side ID
SIDE_NBELEMTYPE   9    ! Neighbouring element type, 0 = No connection to another element
                       !                            1 = Neighbour element is on compute-node
                       !                            2 = Neighbour element is outside of compute node

8.2.1.3. NodeInfo

Node information is read-in and built in ReadMeshNodes

UniqueNodeID = NodeInfo_Shared(NonUniqueNodeID)
! Non-unique node coordinates per element
Coords(1:3) = NodeCoords_Shared(3,1:8*nGlobalElems)

8.2.2. Element/Side Mappings

To get the required element/side ID, utilize one of these functions from the module MOD_Mesh_Tools

! Global element
GlobalElemID = GetGlobalElemID(CNElemID)
! Compute-node element
CNElemID = GetCNElemID(GlobalElemID)
! Global side
GlobalSideID = GetGlobalSideID(CNSideID)
! Compute-node side
CNSideID = GetCNSideID(GlobalSideID)

If a loop is over the local number of elements, the compute-node and global element can be determined with the respective offsets.

DO iElem = 1, nElems
    CNElemID = iElem + offsetComputeNodeElem
    GlobalElemID = iElem + offsetElem
END DO

8.2.2.1. SurfSide

Additionally to conventional sides, mappings for the sides that belong to a boundary condition are available.

DO iSurfSide = 1,nComputeNodeSurfSides
  GlobalSideID = SurfSide2GlobalSide(SURF_SIDEID,iSurfSide)
END DO

8.2.3. Particle Element Mappings

PEM%GlobalElemID(iPart)         ! Global element ID
PEM%CNElemID(iPart)             ! Compute-node local element ID (GlobalElem2CNTotalElem(PEM%GlobalElemID(iPart)))
PEM%LocalElemID(iPart)          ! Core local element ID (PEM%GlobalElemID(iPart) - offsetElem)

8.3. Custom communicators

To limit the number of communicating processors, feature specific communicators can be built. In the following, an example is given for a communicator, which only contains processors with a local surface side (part of the InitParticleBoundarySurfSides routine). First, a global variable SurfCOMM, which is based on the tMPIGROUP type, is required:

TYPE tMPIGROUP
  INTEGER         :: UNICATOR=MPI_COMM_NULL     !< MPI communicator for surface sides
  INTEGER         :: nProcs                     !< number of MPI processes
  INTEGER         :: MyRank                     !< MyRank, ordered from 0 to nProcs - 1
END TYPE
TYPE (tMPIGROUP)    :: SurfCOMM

To create a subset of processors, a condition is required, which is defined by the color variable:

color = MERGE(1337, MPI_UNDEFINED, nSurfSidesProc.GT.0)

Here, every processor with the same color will be part of the same communicator. The condition nSurfSidesProc.GT.0 in this case includes every processor with a surface side. Every other processor will be set to MPI_UNDEFINED and consequently be part of MPI_COMM_NULL. Now, the communicator itself can be created:

CALL MPI_COMM_SPLIT(MPI_COMM_PICLAS, color, MPI_INFO_NULL, SurfCOMM%UNICATOR, iError)

MPI_COMM_PICLAS denotes the global PICLas communicator containing every processor (but can also be a previously created subset) and the MPI_INFO_NULL entry denotes the rank assignment within the new communicator (default: numbering from 0 to nProcs - 1). Additional information can be stored within the created variable:

IF(SurfCOMM%UNICATOR.NE.MPI_COMM_NULL) THEN
  ! Stores the rank within the given communicator as MyRank
  CALL MPI_COMM_RANK(SurfCOMM%UNICATOR, SurfCOMM%MyRank, iError)
  ! Stores the total number of processors of the given communicator as nProcs
  CALL MPI_COMM_SIZE(SurfCOMM%UNICATOR, SurfCOMM%nProcs, iError)
END IF

Through the IF clause, only processors that are part of the communicator can be addressed. And finally, it is important to free the communicator during the finalization routine:

IF(SurfCOMM%UNICATOR.NE.MPI_COMM_NULL) CALL MPI_COMM_FREE(SurfCOMM%UNICATOR,iERROR)

This works for communicators, which have been initialized with MPI_COMM_NULL, either initially during the variable definition or during the split call. If not initialized initially, you have to make sure that the freeing call is only performed, if the respective split routine has been called to guarantee that either a communicator exists and/or every (other) processor has been set to MPI_COMM_NULL.

8.3.1. Available communicators

Handle	Description	Derived from
MPI_COMM_WORLD	Default global communicator	-
MPI_COMM_PICLAS	Duplicate of MPI_COMM_WORLD	MPI_COMM_PICLAS
MPI_COMM_SHARED	Processors on a node	MPI_COMM_PICLAS
MPI_COMM_LEADERS_SHARED	Group of node leaders (myComputeNodeRank = 0, and the root is a node leader as well)	MPI_COMM_PICLAS
MPI_COMM_LEADERS_SURF	Node leaders with surface sides (including halo sides) on a node (might not include the root)	MPI_COMM_LEADERS_SHARED

8.3.1.1. Feature-specific

Handle	Description	Derived from
PartMPIInitGroup(nInitRegions)%COMM	Emission groups	MPI_COMM_PICLAS
SurfCOMM%UNICATOR	Processors with a surface side (e.g. reflective), including halo sides	MPI_COMM_PICLAS
CPPCOMM%UNICATOR	Coupled power potential	MPI_COMM_PICLAS
EDC%COMM(iEDCBC)%UNICATOR	Electric displacement current (per BC)	MPI_COMM_PICLAS
FPC%COMM(iUniqueFPCBC)%UNICATOR	Floating potential (per BC)	MPI_COMM_PICLAS
EPC%COMM(iUniqueEPCBC)%UNICATOR	Electric potential (per BC)	MPI_COMM_PICLAS
BiasVoltage%COMM%UNICATOR	Bias voltage	MPI_COMM_PICLAS

8.3.1.2. Flexi-specific

Following communicators are from flexi and not utilized except in GatheredWriteArray (hdf5_output.f90):

Handle	Description	Derived from
MPI_COMM_NODE	Processors on a node (identical to MPI_COMM_SHARED in PICLas, but not in flexi)	MPI_COMM_PICLAS
MPI_COMM_LEADERS	Group of node leaders (identical to MPI_COMM_LEADERS_SHARED in PICLas, but not in flexi)	MPI_COMM_PICLAS
MPI_COMM_WORKERS	All remaining processors, who are not leaders	MPI_COMM_PICLAS
